Fig. 3

Srrm4 is dynamically expressed at 3 and 5 dpf. a–b″) Single plane images of srrm4 and elavl3 mRNA expression at 3 dpf in 2 focal planes (3 brains averaged). Dorsal views of srrm4 (a, b), elavl3 (a′, b′), and srrm4 and elavl3 merged (a″, b″). c–c″) srrm4 and elavl3 mRNA expression at 5 dpf (5 brains averaged). Dorsal views of srrm4 (c), elavl3 (c′), and srrm4 and elavl3 merged (c″). Areas of overlap, which appear yellow, indicate presumed co-localization. Anterior is to the left. Scale bars = 100 μm. Cc, corpus cerebelli; Ha, habenula; Lc, lobus caudalis; Mo, medulla oblongata; Ot, optic tectum; T, tegmentum; Ts, torus semicircularis.

Expression Data

Genes:	elavl3 srrm4
Fish:	TL
Anatomical Terms:	corpus cerebelli habenula medial caudal lobe optic tectum tegmentum torus semicircularis
Stage Range:	Protruding-mouth to Day 5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
