ZFIN ID: ZDB-FIG-151112-28
Jackson et al., 2015 - Zebrafish Wnt9b Patterns the First Pharyngeal Arch into D-I-V Domains and Promotes Anterior-Medial Outgrowth. American Journal of Molecular Biology   5(3):57-83 Full text @ Am. J. of Molec. Bio.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Fish:
Knockdown Reagent:
Anatomical Term:
Stage: 5-9 somites
PHENOTYPE:
Fish:
Knockdown Reagent:
Observed In:
Stage: 5-9 somites

Fig. 9 Wnt9b morphants exhibit expanded frzb expression in the polster. Top row = dorsal view, bottom row = lateral view, anterior to left. MM control (n = 6) (a), (c) and morphant (n = 15) (b), (d) embryos were aged to 13hpf and stained with frzb riboprobe. 93% of morphant embryos exhibit expanded frzb expression compared to controls. Red arrowheads indicate the polster. Note that morphants have upregulated and expanded expression of frzb. Size bars = 100 ┬Ám.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
frzb AB control 5-9 somites polster ISH
AB + MO2-wnt9b standard conditions 5-9 somites polster ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
AB + MO2-wnt9b standard conditions 5-9 somites polster frzb expression increased amount, abnormal
5-9 somites polster frzb expression increased distribution, abnormal
