FIGURE

Fig. S7

ID

ZDB-FIG-090717-32

Publication

Winata et al., 2009 - Development of zebrafish swimbladder: the requirement of Hedgehog signaling in specification and organization of the three tissue layers

Other Figures

(all 11)

All Figure Page

Back to All Figure Page

Fig. S7

Expression of ptc1 and ptc2 in wild type and Ihha morphant larvae. (A–B) ptc1 expression was reduced in Ihha-MO larvae as compared to that in control. A notable reduction of expression was observable in the endoderm (white arrows) as well as in the brain region (black arrows). (C–D) Expression of ptc2 was also reduced in morphants as compared to control, although some expression remained in the brain (black arrow) and pharyngeal region (white arrows). Abbreviations: sb, swimbladder. Numbers represent anterior somites. Scale bars: 250 μm.

Expression Data

Genes:	ptch1 ptch2
Fish:	AB AB + MO1-ihha
Knockdown Reagent:	MO1-ihha
Anatomical Terms:	brain endoderm pharynx swim bladder
Stage:	Pec-fin

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	AB + MO1-ihha
Knockdown Reagent:	MO1-ihha
Observed In:	smoothened signaling pathway swim bladder swim bladder formation
Stage:	Pec-fin

Phenotype Detail
