FIGURE

Fig. 8

ID

ZDB-FIG-260311-274

Publication

Luo et al., 2025 - General transcription factor IIIAa regulates the transcription of somatic 5S rRNA and influences embryonic organ development in zebrafish

Other Figures

All Figure Page

Back to All Figure Page

Fig. 8

Loss of gtf3aa affects liver and intestine development. A, B In situ hybridization of fabp10a in the liver of 3-dpf gtf3aa^+/+ and gtf3aa^−/− larvae. C, D In situ hybridization of tfa in the liver. E, F In situ hybridization analysis of fabp2 in the intestine. G, H H&E staining of the liver in gtf3aa^+/+ and gtf3aa^−/− larvae. I, J H&E staining of the liver in gtf3aa^+/+ larvae and gtf3aa^−/− mutants rescued by gtf3aa mRNA injection at the one-cell stage. K, L H&E staining of the liver in vehicle-injected gtf3aa^+/+ and gtf3aa^−/− larvae. M, N H&E staining of the intestine in gtf3aa^+/+ and gtf3aa^−/− larvae. O, P H&E staining of the intestine in larvae rescued by mRNA injection. Q, R H&E staining of the intestine in vehicle-injected larvae. All comparisons are between gtf3aa^+/+ and gtf3aa^−/− groups

Expression Data

Genes:	fabp2 fabp10a tfa
Fish:	AB gtf3aa^{ihb950/ihb950} (AB)
Anatomical Terms:	intestine liver
Stage:	Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	gtf3aa^{ihb950/ihb950} (AB)
Observed In:	intestine liver
Stage:	Protruding-mouth

Phenotype Detail
