FIGURE

Fig. 3

ID

ZDB-FIG-080715-28

Publication

Liu et al., 2008 - In vivo time-lapse imaging delineates the zebrafish pituitary proopiomelanocortin lineage boundary regulated by FGF3 signal

Other Figures

(all 7)

All Figure Page

Back to All Figure Page

Fig. 3

Expression of Prl, Gh, and Pit-1 in FGF3 morphants are intact. In situ hybridization at 56 hpf using probes indicated in the lower right corner of each panel. (A–D) Wild type embryos. (E–H) Low dose FGF3 morphants with diminished POMC-GFP expression in the pars intermedia. (I–L) High dose FGF3 morphants with diminished POMC-GFP expression in the pars intermedia and rostral pars distalis. Ventral view of head, anterior to the left. Arrowheads, RPD. Arrow, PI. P, pituitary; Hy, hypothalamic POMC cells. Scale bar, 50 μm.

Expression Data

Genes:	gh1 pomca pou1f1 prl
Fish:	WT zf44Tg + MO1-fgf3
Knockdown Reagent:	MO1-fgf3
Anatomical Terms:	adenohypophyseal placode hypothalamus pars anterior pars intermedia
Stage:	Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	zf44Tg + MO1-fgf3
Knockdown Reagent:	MO1-fgf3
Observed In:	adenohypophysis morphogenesis pars intermedia
Stage:	Long-pec

Phenotype Detail
