FIGURE

Fig. 4

ID

ZDB-FIG-231229-10

Publication

Nikaido et al., 2023 - Intestinal expression patterns of transcription factors and markers for interstitial cells in the larval zebrafish

Other Figures

All Figure Page

Back to All Figure Page

Fig. 4

The intestinal expression of pdgfra gene at different stages. (a–c) Expression of pdgfra gene in the middle and distal part of the intestine at 3 dpf (a) and 6 dpf (b, c). Panel c shows its expression in the intestinal bulb. Skin is removed in the 6 dpf larvae for better observation. Purple signals are observed in the intestine (purple triangles). Left side views. Anterior, to the left. Stages examined are shown in the top-right corners. (d–g) Cross sections at the level of anterior part of the intestinal bulb (d), posterior part of the intestinal bulb (e), and middle part of the intestine (f). Panel g is a close-up image of the indicated area in panel f. Purple triangles indicate expression of pdgfra outside of the mucosal layer. Scale bar: 50 μm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Growth Diff.
