Fig. 2

Expression patterns of hoxb1b-regulated genes. 30 genes identified as up-regulated by hoxb1b (see Table 1 and Table S1) were assayed by in situ hybridization to determine their expression patterns. All embryos are at 14hpf and are shown as whole mounts in dorsal view with anterior to the top. The Unigene ID for each gene is given in the lower right of each panel and corresponds to the Unigene IDs in Table 1 and Table S1.

Expression Data

Genes:	afap1l1a col28a2a crabp1a dusp23a egfl6 epha4a ets1 foxd3 gas6 greb1l hnf1bb irx5a kctd12.2 kirrel3l mmp2 myclb nab1a nck2a ppp1r14ab prdm12b sulf2b tfap2a tox3 wu:fa10d10 wu:fc11e07 wu:fc17g06 wu:fc30f10 wu:fc51e09 zwi
Fish:	WT
Anatomical Terms:	hindbrain hindbrain lateral region lateral mesoderm rhombomere rhombomere anatomical compartment boundary rhombomere 2 rhombomere 3 rhombomere 4 rhombomere 5 rhombomere 6 whole organism
Stage:	10-13 somites
Probe:	fc66b04

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 358(2), Choe, S.K., Zhang, X., Hirsch, N., Straubhaar, J., and Sagerström, C.G., A screen for hoxb1-regulated genes identifies ppp1r14al as a regulator of the rhombomere 4 Fgf-signaling center, 356-67, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
