Fig. 2

Morphological and molecular analysis of bal, gup and sly mutant embryos. Lateral views show wild-type (WT) (A, G), bal (D, K), gup (H) and sly (L) embryos at 3 day post fertilisation. Staining with a polyclonal antibody generated against mouse laminin 1 (α1β1γ1) detects expression pattern in 24 hpf WT (B) embryos. Laminin immunoreactivity in 24 hpf bal mutant embryos (E) is at wild-type levels within the posterior notochord (arrowhead), but severely reduced immunoreactivity is seen in the non-differentiated anterior notochord, and intersomitic boundaries. In 24 hpf gup (I) and sly (M) embryos, laminin 1 immunoreactivity is abolished. The developing vasculature is marked by expression of fli-1 mRNA in 24 hpf WT (C) and bal (F), gup (J) and sly (N) mutant embryos.

Expression Data
Genes:
Fish:
Anatomical Terms:
Stage Range: 14-19 somites to Prim-5

Expression Detail
Antibody Labeling
Phenotype Data
Fish:
Observed In:
Stage: Prim-5

Phenotype Detail
