Figure Caption

Fig. 3

Hindbrain expression patterns of hoxb1b-regulated genes. 18 hoxb1b-regulated genes identified as expressed in the hindbrain were assayed by themselves (1st and 3rd column) or as double in situ hybridization together with krox20 (2nd and 4th column; krox20 is expressed in r3 and r5 and is detected in red). Based on the double in situ hybridizations, it was determined which rhombomeres express each of the novel genes and this is indicated in each panel in columns 1 and 3. All embryos are at 14hpf and are shown as whole mounts in dorsal view with anterior to the top. In situ panels in columns 1 and 3 are duplicated from Fig. 2 for ease of comparison.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 358(2), Choe, S.K., Zhang, X., Hirsch, N., Straubhaar, J., and Sagerström, C.G., A screen for hoxb1-regulated genes identifies ppp1r14al as a regulator of the rhombomere 4 Fgf-signaling center, 356-67, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
