Fig. 5

PPARγ in swim bladder development. A: Representative morphology and ORO staining of sibling 5dpf chd7^+/+ (vehicle treated) and B: BADGE treated larvae with close up of caudal vein region C: ORO staining showing neutral lipid droplet accumulation in the eye vasculature and swim bladder (arrows) of 5dpf chd7^+/+(vehicle treated), chd7^−/− mutants and BADGE treated chd7^+/+ larvae. D: Representative morphology and ORO staining of 5dpf chd7^+/+ and (E) chd7^−/− mutants larvae treated with RGZ, with a close-up of the caudal vein region. A–E: representative images for 3 independent experiments (n = 5larvae per condition and genotype). F. RT-qPCR of key swim bladder lipid metabolism markers fabp7b, elov1a, anxa5b and cebpa in chd7^+/+ (vehicle-treated), early and late onset BADGE-treated and RGZ-treated larvae. RT-qPCR were performed with sibling wildtype (chd7^+/+) larvae of 3 separate clutches (N) (N = 3 from 15 pooled fish per sample/genotype; significance: ∗P < 0.05; ∗∗P < 0.01; ∗∗∗P < 0.001; Error bars represent SD).

Expression Data

Genes:	anxa5b cebpa elovl1a fabp7b
Fish:	WT
Conditions:	chemical treatment by environment: Bisphenol A diglycidyl ether chemical treatment by environment: rosiglitazone
Anatomical Term:	whole organism
Stage:	Day 5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT chd7^{zf4383/zf4383}
Conditions:	chemical treatment by environment: Bisphenol A diglycidyl ether chemical treatment by environment: rosiglitazone
Observed In:	ocular blood vessel lipid droplet swim bladder lipid swim bladder lipid droplet swim bladder lipid transport vasculature lipid whole organism whole organism lipid yolk lipid yolk lipid transport
Stage:	Day 5

Phenotype Detail
