Different shades of orange in developing GloFish with the same genotype. Comparisons between selected red and orange fish resulting from the indicated test crosses. The squares to the right of each group of whole pictures are magnified views of the fish in a region just posterior to the pectoral fin, arranged in the same order as the whole fish pictures. Arrows in the images for Crosses A and B indicate the location of the pectoral fins. Note that there are different shades of orange fish in crosses A and B even though they all have the same complement of transgenes. All images are lateral views with anterior to the left. |
