Fig. 4
- ID
- ZDB-FIG-081010-11
- Publication
- Gansner et al., 2008 - Essential role for fibrillin-2 in zebrafish notochord and vascular morphogenesis
- Other Figures
- (all 11)
- All Figure Page
- Back to All Figure Page
pfdgw1 mutants are sensitized to pharmacologic inhibition of lysyl oxidase. A-F: Clutches from pfdgw1/+ intercrosses were incubated in vehicle (A,B), the copper chelator neocuproine (2 μM; C,D), or the lysyl oxidase inhibitor β-aminopropionitrile (1 mM; E,F). Notochord is normal in wild-type embryos treated with vehicle or neocuproine (A,C) and shows a very mild herniation event in β-aminopropionitrile (E, arrowhead). Notochords of pfdgw1 mutants in neocuproine and β-aminopropionitrile (D,F, arrowheads) are substantially more distorted than mutants incubated in vehicle (B, arrowhead). Embryos were incubated in PTU to inhibit melanin pigmentation and photographed at 30 hours postfertilization (hpf). |
Fish: | |
---|---|
Observed In: | |
Stage: | Prim-15 |
