Fig. S4

Med12 regulates anterior sox17 expression in endodermal cells during gastrulation. Wild-type and med12s432 mutants were analyzed at 60% (A–B′) and 90% (C–E′) epiboly for bon (A, A′), gata5 (B, B′), sox17 (C, C′), foxa2 (D, D′), and cas (E, E′) expression. White dashed lines in C and C′ surround a subset of sox17-positive cells in the anterior region. Note that, in med12s432 mutants, many of these cells are missing, whereas other early endodermal markers show comparable expression in wild-type and mutants. After in situ hybridization, the embryos were genotyped to unambiguously identify the mutants. A–B′ are animal pole views; C–E′ are dorsal views, anterior to the top.

Expression Data
Genes:
Fish:
Anatomical Terms:
Stage Range: Shield to 90%-epiboly

Expression Detail
Antibody Labeling
Phenotype Data
Fish:
Observed In:
Stage: 90%-epiboly

Phenotype Detail
