Fig. 5

Med12 regulates her5 expression in endodermal cells during gastrulation and somitogenesis. (A, A′) In situ hybridization at 90% epiboly shows specific reduction of her5 expression in endodermal cells in med12^s432 mutants compared to wild-type siblings. The V shaped stripe represents the domain of her5 expression in the midbrain–hindbrain boundary. (B–D′) Injection of med12 MO into the Tg(-0.7her5:EGFP)^ne2067 line caused decreased GFP expression. Note that the Tg(-0.7her5:EGFP)^ne2067 line shows GFP expression in the pharyngeal endoderm as well as the organ-forming region during late somitogenesis stages (C, D). White bracket in C–D′ indicates pharyngeal region. Exposure time for imaging B, B′ was 300 ms; C, C′ was 250 ms; D, D′ was 250 ms. Dorsal views, anterior to the top.

Expression Data

Genes:	EGFP her5
Fish:	WT med12^s432/s432 ne2067Tg ne2067Tg + MO5-med12
Knockdown Reagent:	MO5-med12
Anatomical Terms:	digestive system endoderm endodermal cell midbrain hindbrain boundary neural plate pharyngeal endoderm
Stage Range:	90%-epiboly to 20-25 somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
