Fig. 5

prkacβb neuronal expression patterns. Brightfield images of zebrafish embryos processed for in situ hybridization. (A–C) Whole-mount lateral, (A′-C′) whole-mount dorsal. Brightfield sections (A″-C″) forebrain, (A‴-C‴) midbrain and (B‴‘-C‴‘) hindbrain. Embryos were imaged at different developmental time points. (A-A‴) 24 hpf, (BB‴‘) 48 hpf, (CC‴‘) 72 hpf. Lines in (A–C) indicate locations of the sections shown at that time-point. Hpf-hours post fertilization, FBfin bud, RGC- retinal ganglion cell layer, Hi-intermediate hypothalamus, OV otic vesicle, T-thalamus, INL-inner nuclear layer, MO- medulla oblongata, n.s-non-specific. Inset shows sense probe control.

Expression Data

Gene:	prkacbb
Fish:	AB
Anatomical Terms:	fin bud hypothalamus medulla oblongata otic vesicle retina retinal ganglion cell layer retinal inner nuclear layer thalamus
Stage Range:	Prim-5 to Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 31, Emerson, S.E., Grebber, B.K., McNelllis, M., Orr, A.R., Deming, P.B., Ebert, A.M., Developmental expression patterns of protein kinase A catalytic subunits in zebrafish, 1-6, Copyright (2018) with permission from Elsevier. Full text @ Gene Expr. Patterns
