Fig. 10

ID
ZDB-FIG-150325-20
Publication
Mommaerts et al., 2014 - Smoc2 modulates embryonic myelopoiesis during zebrafish development
Other Figures
All Figure Page
Back to All Figure Page
Fig. 10

smoc2 morphants do not display cardiovascular defects. Dorsal (A–D: anterior to the top; E–H: anterior to the left) and lateral view (I–R′ anterior to the left) of embryos at 12 ss (A,B,E,F), 20 ss (C,D,G,H), the onset of blood cell circulation (I–P) and 50 hpf (Q,R′). Analysis of the expression pattern of the early cardiac marker nkx2.5 (A–D), the vascular marker fli (E–H), the dorsal aorta marker vegfc (I,J), the marker for all venous and arterial cells flt4 (K,L), the endothelial marker flk1 (M,N) and the arterial marker dll4 (O,P) (n ≥ 14). Q–R′: Visualization of the fli-positive vasculature using the (Tg(fli:eGFP)y1) reporter fish at 50 hpf.

Expression Data
Genes:
Fish:
Knockdown Reagents:
Anatomical Terms:
Stage Range: 10-13 somites to Long-pec

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
