FIGURE

Fig. 4

ID

ZDB-FIG-140909-3

Publication

Majumdar et al., 2000 - The zebrafish floating head mutant demonstrates podocytes play an important role in directing glomerular differentiation

Other Figures

All Figure Page

Back to All Figure Page

Fig. 4

flh embryos make functional glomeruli as assayed by filtration of rhodamine dextran dye. Rhodamine dextran dye (red) has been injected into the sinus venosus, filtered through the glomerulus, and taken up into duct endosomes (arrow) in 2-dpf wildtype embryos (A, B). Note that no dye is retained in the glomerulus (asterisk in A). WGA staining (green) positively identifies the duct apical brush border. In 2-dpf flh embryos (C) injected with rhodamine dextran, dye is found in the cardinal vein (arrowhead), ectopic glomeruli (asterisk), and duct endosomes (arrow). Dye is frequently trapped in glomeruli. Sections in B and C have not been stained with WGA.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	noto^n1/n1 (AB)
Observed In:	glomerular filtration whole organism
Stage Range:	Protruding-mouth to Day 4

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 222(1), Majumdar, A. and Drummond, I.A., The zebrafish floating head mutant demonstrates podocytes play an important role in directing glomerular differentiation, 147-157, Copyright (2000) with permission from Elsevier. Full text @ Dev. Biol.
