FIGURE

Fig. 2

ID

ZDB-FIG-101123-49

Publication

Gamba et al., 2010 - Estrogen receptor ESR1 controls cell migration by repressing chemokine receptor CXCR4 in the zebrafish posterior lateral line system

Other Figures

All Figure Page

Back to All Figure Page

Fig. 2

Migration of the PLL primordium is altered in esr1-MO embryos. (A) Three frames of a time-lapse movie of primordium migration in a cldnb:gfp embryo at 35 (t = 0), 38, and 41 hpf, respectively. At 41 hpf, the primordium has just migrated out of the field. (B) Five frames of a time-lapse movie of the primordium in an esr1-MO1 injected embryo at 35 (t = 0), 38, 41, 44, and 48 hpf, respectively. Migration is two to three times slower than in untreated cldnb:gfp embryos and eventually comes to a halt around 45 hpf. (C) In the same embryo, the immobile primordium has fragmented into two neuromasts at 51 hpf. (Scale bar in A: 50 μm.)

Expression Data

Gene:	EGFP
Fish:	ump1Tg; zf106Tg ump1Tg; zf106Tg + MO1-esr1
Knockdown Reagent:	MO1-esr1
Anatomical Term:	posterior lateral line primordium
Stage Range:	Prim-15 to High-pec

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	ump1Tg; zf106Tg + MO1-esr1
Knockdown Reagent:	MO1-esr1
Observed In:	posterior lateral line neuromast primordium migration posterior lateral line primordium
Stage Range:	Prim-15 to High-pec

Phenotype Detail
