Fig. 3
(A and B) The myl7:TetA-GBD Cherry transgene is expressed in the adult heart. (A) Brightfield images of whole extracted adult hearts: (Left) WT; (Right) myl7:TetA-GBD Cherry heterozygous. (B) Cherry channel. Note Cherry expression in ventricle (*) and weakly in atrium (arrowhead). (C and D) Inducibility in adult hearts. Cryosections of adult hearts of myl7:TetA-GBD Cherry; TetRE:Axin1-YFP double transgenic fish that had been injected intraperitoneally with EtOH (C) or 20 μg Dox plus 5 μg Dex (D). Axin1-YFP is detected by anti-GFP antibody. n = 6 EtOH and Dox/Dex. |
