FIGURE

Fig. 7

ID

ZDB-FIG-091117-18

Publication

van Eeden et al., 1996 - Genetic analysis of fin formation in the zebrafish, Danio rerio

Other Figures

All Figure Page

Back to All Figure Page

Fig. 7

Phenotype of ddf mutant embryos. Wild type (A) and ddf mutant (B) at the 15-somite stage. Rounded-up cells are predominantly present on the head and the prospective hindbrain. The head is apposed more closely to the yolk compared to wild type. (C,D) 5-day-old wild type and ddf mutant, respectively. Rounded-up cells are now easily visible in the fins. The angle between head and trunk appears normal at this stage.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	ddf^ta50
Observed In:	fin cell head head integument integument cell
Stage Range:	14-19 somites to Day 5

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
