Fig. 2

Mutants in which the entire fin fold is affected. (A) Wild-type tail fin lateral view, 48 hpf. Note the thin lines that are running from the base to the tip of the fin, which represent the actinotrichia. Nagel (B), frayed (C), rafels (D), blasen (E) and pinfin (F) mutants, respectively. In nel and pif mutants the bubbly appearance is still visible; later the fin fold will degenerate. (G) Wild-type tail fin, ventral view. (H) frilly fins mutant tail fin, ventral view. The undulations in the fin fold are most pronounced at the tip of the tail.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	fras1^tm95b/tm95b frem1a^tr240/tr240 frem2a^ta90/ta90 hmcn1^tq207/tq207 itga3b^tj2b/tj2b bmp1a^tf5/+; bmp1a^tm317a/+ (all 6)
Observed In:	integument cell ventral fin fold ventral fin fold epidermis
Stage:	Long-pec
