Fig. 4

Recovery of myog expression upon initial down-regulation in six1a morphants. Flat mount embryos after WISH for myog. Wild-type embryos (A, C, E) and UM morphants (B, D, F). Arrowheads mark myog expression in fast muscle precursors. Note that the myog expression is nearly absent along the entire posterior border in all somites in morphants at 9 s, increased at 10 s and recovered at 13 s. Also note the delay of recovery in the most posterior somites at 13 s (brackets). Scale bar, 100 μm.

Expression Data

Gene:	myog
Fish:	AB AB + MO4-six1b
Knockdown Reagent:	MO4-six1b
Anatomical Terms:	adaxial cell fast muscle cell segmental plate somite
Stage Range:	5-9 somites to 10-13 somites

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	AB + MO4-six1b
Knockdown Reagent:	MO4-six1b
Observed In:	somitomeric trunk muscle development striated muscle cell differentiation
Stage Range:	5-9 somites to 10-13 somites

Phenotype Detail
