FIGURE

Fig. S1

ID
ZDB-FIG-081028-18
Publication
Ahn et al., 2008 - Tri-phasic expression of posterior Hox genes during development of pectoral fins in zebrafish: Implications for the evolution of vertebrate paired appendages
Other Figures
All Figure Page
Back to All Figure Page
Fig. S1

Late expression of hoxa9a/a11a in pectoral fin muscle cells in zebrafish. By 48 hpf, pectoral fin muscle cells can be recognized by the expression of several marker genes such as myoD (A, D), which is not expressed during the migration of fin muscle cells (24–30 hpf: not shown). At this stage, it is clear that the expression of hoxa9a (B, E) and hoxa11a (C, F) is mostly confined to the pectoral fin muscle cells. Note that, for hoxa9a, expression is much weaker in the medial cluster of muscle cells compared to the lateral cluster of muscle cells. For hoxa11a, expression is also seen in the distal mesenchyme cells (arrow in B) in addition to the pectoral fin muscle cells. A–C: lateral view of left pectoral fins. D–F: dorsal-posterior view of pectoral fins and surrounding regions. l: lateral cluster of fin muscle cells. m: medial cluster of fin muscle cells. pHM: posterior hypaxial muscle.

Expression Data
Genes:
Fish:
Anatomical Terms:
Stage: Long-pec

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 322(1), Ahn, D., and Ho, R.K., Tri-phasic expression of posterior Hox genes during development of pectoral fins in zebrafish: Implications for the evolution of vertebrate paired appendages, 220-233, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
