Fig. 6

Xanthophores are qualitatively reduced in number and size in enz mutants.
(A, B) fms expression in 48 hpf wild-type (A) and enz mutant (B) embryos. Qualitatively reduced fms expression suggests that fewer xanthophores are present in enz mutants than in wild-type siblings at this stage (arrowheads in A and B). (C, D) Methylene blue-stained xanthophores appear much larger in wild-type (C) embryos than in enz mutants (D) at 3 dpf.

Expression Data

Gene:	csf1ra
Fish:	WT enz^b431 (AB)
Anatomical Term:	xanthophore
Stage:	Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	enz^b431 (AB)
Observed In:	xanthophore
Stage Range:	Long-pec to Protruding-mouth

Phenotype Detail
