Fig. 8
Expression of the fms gene in the early macrophage lineage. (A) 25-somite (21.5 hpf), dorso-lateral view; beside pre-/young macrophages spread on the yolkball, fms-positive xanthophore precursors outline the lateral borders of the neural tube (nt); (e) eye. (B) 48 hpf, head, deep dorsal view. Out-of-focus fms-positive macrophages produce the multiple shadows. (ol) olfactory organ; (ac) anterior commissure; (oc) optic chiasm. (C) 72 hpf, lateral view. Bars: (A, C) 50 μm; (B) 20 μm. |
