Fig. 7

Expression patterns of selenoproteins SePH (A–C) and selenophosphate synthetase SPS2 (D–F) in zebrafish embryos. The development stage is indicated in the right corner of each panel in hours post-fertilization. BVZ, brain ventricular zone; IB, intestinal bulb; K, kidney; L, liver; MY, myotomes; OV, olfactory vesicle; PD, pronephric duct; PF, pectoral fins; PT, posterior tectum; PZR, proliferative zone of the retina; R, retina; TE, tectum.
