FIGURE

Fig. 4

ID

ZDB-FIG-080418-14

Publication

Herzog et al., 2003 - Adenohypophysis formation in the zebrafish and its dependence on sonic hedgehog

Other Figures

All Figure Page

Back to All Figure Page

Fig. 4

The pituitary anlage moves into the head via a common invagination of the hypophyseal-stomodeal placode. (A–G, I, J) pomc expression. (H) gh expression. Embryos in (B) and (G) are counterstained for nk2.1 in red. Ages of embryos are indicated in bottom-right corner (hpf, hours after fertilization). (A–G) Lateral views. (H) Transverse section through pituitary (compare with histological sections of larvae at 72 and 120 hpf at http://zfin.org/zf_info/anatomy/dev_atlas.html). (I, J) Frontal views (with magnification of pituitary region in insets). (D) Magnified pituitary region of embryo shown in (C). Putative hypothalamic pomc-positive cells in (A, C, E, G, J) are indicated by arrows. Note the progressive spreading of pomc-positive cells along the anteroposterior axis in (A–E), leading to two distinct pomc domains at the anterior and posterior ends of the pituitary anlage (F, G). Abbreviations: oc, oral cavity; fg, foregut; ca, cartilage.

Expression Data

Genes:	gh1 nkx2.4b pomca
Fish:	WT
Anatomical Terms:	adenohypophyseal placode adenohypophysis hypothalamus pars intermedia rostral pars anterior
Stage Range:	Prim-5 to Day 5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 254(1), Herzog, W., Zeng, X., Lele, Z., Sonntag, C., Ting, J.W., Chang, C.Y., and Hammerschmidt, M., Adenohypophysis formation in the zebrafish and its dependence on sonic hedgehog, 36-49, Copyright (2003) with permission from Elsevier. Full text @ Dev. Biol.
