FIGURE

Fig. 4

ID
ZDB-FIG-071116-15
Publication
Blanco et al., 2007 - Snail1a and Snail1b cooperate in the anterior migration of the axial mesendoderm in the zebrafish embryo
Other Figures
All Figure Page
Back to All Figure Page
Fig. 4

snail1b expression is excluded from the hgg1 expression domain within the axial mesendoderm. (A). Dual fluorescent in situ hybridisation demonstrates that snail1b expression is excluded from the hgg1-positive prechordal plate cells. The domains occupied by the two populations have ill-defined borders (B). (C) Sagittal sections of the embryo shown in A (dotted line) reveal the intermingling of the adjacent cell populations. Inset: border region at higher magnification. (D) At the tailbud stage, the cells have sorted out and a sharp boundary is defined. (E-G) The hgg1-positive prechordal plate cells also express cdh1 transcripts.

Expression Data
Genes:
Fish:
Anatomical Terms:
Stage Range: 90%-epiboly to Bud

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
