Fig. 2

SB-431542 rapidly blocks transcription of Nodal target genes. lefty1 expression in embryos treated with DMSO (A-C) or SB-431542 (D-F) at 4.3 h (dome stage), and fixed after 15 minutes (A, D), 30 minutes (B, E) or 45 minutes (D, F).

Expression Data

Gene:	lft1
Fish:	WIK
Condition:	chemical treatment: pharmaceutical
Anatomical Term:	unspecified
Stage:	Dome

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
