FIGURE

Fig. 7

ID
ZDB-FIG-050516-5
Publication
Nicoli et al., 2005 - Regulated expression pattern of gremlin during zebrafish development
Other Figures
All Figure Page
Back to All Figure Page
Fig. 7

Expression pattern of grm in WT, fgf8 and shh mutant embryos during somitogenesis and at 22 hpf. Shown are wild-type (A,D,G), aceti282a (B,E,H), and syutbx392 (C, F, I) embryos, stained with a grm probe. Arrows in (D,F) point to grm expression in the anterior mesoderm, and arrow heads in (D,E) to the nascent somites. In (H,I), the arrow heads indicate grm staining in the anterior mesoderm and ventral neural tube, and the arrows point to the restricted grm signal in the posterior region of the mutant embryos. Embryos are oriented with anterior to the top (A–C,G–I), or to the left (D–F). (A–C) are dorsal views, (D–I) lateral views.

Expression Data
Gene:
Fish:
Anatomical Terms:
Stage Range: 10-13 somites to 26+ somites

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 5(4), Nicoli, S., Gilardelli, C.N., Pozzoli, O., Presta, M., and Cotelli, F., Regulated expression pattern of gremlin during zebrafish development, 539-544, Copyright (2005) with permission from Elsevier. Full text @ Gene Expr. Patterns
