ZFIN Image: Kawahara et al., 2018, Fig. 5


Figure Caption

Fig. 5 Effect of a Notch signaling inhibitor, DAPT, on slurp-like1 expression. (A–D) Wild-type embryos at 6 hpf (A, B) were exposed to 100 μM DAPT (Notch signal inhibitor: B) or the same volume of DMSO (control: A) and incubated at 28.5 °C until 24 hpf, while wild-type embryos at 16 hpf (C, D) were incubated with 100 μM DAPT (D) or DMSO (C) and incubated until 24 hpf. The expression of slurp-like1 was examined by WISH using the antisense slurp-like1 RNA probe. The slurp-like1 expression in the hypochord (arrowhead) was strongly inhibited in the embryos treated with early DAPT treatment (B; 6 hpf), while its expression was partly inhibited in the embryos with late DAPT treatment (D; 16 hpf). The slurp-like1 expression in the floor plate (arrow) was not affected. Scale bars, 100 μm.

Figure Data

Expression / Labeling details

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 30, Kawahara, A., Morita, H., Yanagi, K., Ishizaka, T., Taimatsu, K., Ohga, R., Developmental expression of the slurp-like1/ly2.3/ly97.3 and slurp-like2/ly2.2/ly97.2 genes during zebrafish early embryogenesis, 32-36, Copyright (2018) with permission from Elsevier. Full text @ Gene Expr. Patterns
