ZFIN Image: Porreca et al., 2012, Fig. 3


Figure Caption

Fig. 3 bcl2l expression in the zebrafish thyroid is not controlled bypax8. Lateral views with anterior to the left. Stage is indicated at bottom left, experimental morpholino at bottom right and marker at top right. (A) and (B) bcl2l expression in control (A) and in pax8 morphant embryos (B) is similar. (A′, B′) Morphology of the otic vesicles in control (A′) and pax8 morphant embryo (B′) at 24 hpf showing the efficiency of the injected MO (Mackereth et al., 2005). (C) and (D) hhex expression in the thyroid primordium of control (C) and pax8 morphant embryo (D) is similar. Arrow indicates the thyroid primordium.

Figure Data

Expression / Labeling details

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 366(2), Porreca, I., De Felice, E., Fagman, H., Di Lauro, R., and Sordino, P., Zebrafish bcl2l is a survival factor in thyroid development, 142-152, Copyright (2012) with permission from Elsevier. Full text @ Dev. Biol.
