Fig. 2

ID
ZDB-IMAGE-080715-35
Genes
Source
Figures for Dutta et al., 2008
Figure Caption

Fig. 2 At the 20-somite (19 h) stage, pituitary placode cells express deltaA, deltaB, and deltaD in a salt and pepper pattern. Wild-type embryos are labeled with probes for deltaA (A, E, n = 19), deltaB (B, F, n = 28), and deltaD (C, G, n = 25). (D) Expression of notch1a (blue, n = 20) and prl (red, n = 20) does not colocalize in the pituitary placode at prim-5 stage (24 h). (H) Cells in the pituitary placode co-express pitx3 (red, n = 20) and deltaA (blue, n = 20). (A–H) Arrowheads indicate cells in the pituitary placode, asterisk indicates optic recess. (A–C) Side views, anterior to the left, dorsal to the top; (D–H) frontal views, dorsal to the top. Scale bar: 50 μm (A–C, E–G), 20 μm (D, H).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 319(2), Dutta, S., Dietrich, J.E., Westerfield, M., and Varga, Z.M., Notch signaling regulates endocrine cell specification in the zebrafish anterior pituitary, 248-257, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
