Fig. 2

ID
ZDB-IMAGE-080604-63
Genes
Source
Figures for Kassen et al., 2008
Figure Caption

Fig. 2 Expression of the cyclin B1:EGFP transgene at 48 hpf. A: A fluorescent image of a Tg(ccnb1:EGFP)nt18 embryo at 48 hpf is displayed. EGFP was expressed throughout the body of the fish with the most intense expression in the brain (arrow) and eye field (arrowhead). A bright-field image of the same embryo is shown in the inset. B: Whole-mount in situ hybridization revealed cyclin B1 mRNA expression throughout the body with the greatest staining in the head (arrow) and eye (arrowhead). A zebrafish labeled with the cyclin B1 sense RNA probe is shown in the inset. Retinal sections at 48 hpf reveal strong PCNA expression in cells in the retinal margin (C), which is similar to EGFP expression (D). EGFP and PCNA expression is decreased in the central retina (*). Retinal sections labeled with the cyclin B1 antisense RNA probe demonstrated a similar high level of expression near the retinal margin (E, arrows), while the control sense RNA probe did not label any retinal cells. F: No signal was observed with the sense RNA probe. Abbreviations: RPE represents retinal pigmented epithelium, and GCL represents ganglion cell layer.

Figure Data
