Fig. 4

ID
ZDB-IMAGE-061121-3
Genes
Source
Figures for Muller et al., 2006
Figure Caption

Fig. 4 Prdc expression in somites, swim bladder, and oral epithelium. A-C: prdc is expressed primarily in the ventral part of the developing somites at 24 hours postfertilization (hpf; arrowheads). B and C are plastic sections of the whole-mount prdc in situ hybridization shown in A. The section planes are marked with the lines B and C. D-F: prdc (in blue) and foxa3 (in red) expression at 32, 36, and 42 hpf (D-F). The two probes overlap at the site of the swim bladder bud. The prdc expression in pharyngeal arches is also visible at the top. G: Single foxa3 staining marks the liver (L), swim bladder (S), pancreas (P), and buds and the intestinal bulb (IB). H,I: sections of prdc probe-stained embryos depict expression in the swim bladder mesenchyme (arrowheads) at 42 and 72 hpf. J,K: prdc expression at 72 hpf marks the oral epithelium in whole-mount staining and sections (white arrowheads). Staining in the arches is also seen (black arrowhead in K). Anterior is to the top in panels A, D-G and to the left in J. h, hours postfertilization.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
