Figure Caption

Fig. 3 ascl1a mutants show decreased expression of the lim3, pitx3 and ascl1a, and fail to initiate expression of neurod, pit1 and all adenohypophyseal hormone genes, whereas the hypothalamus appears unaffected. Columns 1 and 3 show wild-type siblings (wt); columns 2 and 4 show pia mutants. Probes used for whole-mount in situ hybridization are indicated in lower right-hand corners, ages of embryos in the upper right-hand corners of wild types. (A,C,E,F,G,N) Lateral views, anterior towards the right, dorsal upwards. (B,D,H-M) Dorsal views, anterior towards the right. Arrows in A-H indicate expression in the adenohypophysis. Inset in E shows section through pituitary of pia mutant at 120 hpf (see Fig. 2J for wild-type control). h, hypothalamus.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
