Fig. 2

ID
ZDB-IMAGE-051118-1
Genes
Source
Figures for Park et al., 2005
Figure Caption

Fig. 2 Netrin mRNA expression in zebrafish embryos. Netrin1a, netrin1b, and netrin2 expression domains were analyzed by RNA in situ hybridization during the first 3 days of embryonic development. A-H: Lateral (A,B,D-F,H) and dorsal (C,G) views of netrin1a (A-D) and netrin1b (E-H). A,B: netrin1a is expressed in the brain, spinal cord, and somites at 24 hpf. C,D: By 36 hpf, somite expression has diminished and expression is visible in the optic nerve. E,F: netrin1b is detected in the ventral brain, the floor plate of the spinal cord, and the hypochord at 24 hpf. G,H: Hypochord expression diminishes by 30 hpf. I-V: Dorsal (I,K,M,Q,T) and lateral (J,L,N-P,R,S,U,V) views of netrin2 expression at stages indicated. I,J: netrin2 is expressed in the fourth rhombomere (arrow) and in the otic vesicle (arrowhead) at 24 hpf. K: krox20 two-color in situ hybridizations confirm rhombomere 4 localization of netrin2 (arrow). L: netrin2 is expressed in the ventral somites (So) at 24 hours postfertilization (hpf). M,N: At 36 hpf, netrin2 expression extends to the dorsal and ventral margins of the otic vesicle (arrowhead) and in the hindbrain region. O: Enlarged view of the hindbrain and otic vesicle (arrowhead). P: netrin2 is also detected in notochord (Not) and spinal cord (SC) after prolonged colorimetric development. Q,R: At 48 hpf, netrin2 is expressed in bilateral clusters in the telencephalon (small arrowhead), around the medial and caudal margins of the tectum, in the cerebellum, and along the dorsal hindbrain, and in the ventromedial margin of the otic vesicles. It is also expressed in the pharyngeal arches and pectoral fins (small arrows). In contrast to netrin1a and 1b, expression in the brain is primarily constrained to the dorsal aspect. S: Higher magnification views of the hindbrain and otic vesicle; arrowhead denotes the strong expression in the ventral margin of the otic epithelium. T,U: By 72 hpf, expression in the pharyngeal arches is robust, and expression in the dorsal aspect of the otic epithelium and pectoral fins (small arrow) has strengthened. V: Higher magnification view of the otic vesicle; the arrowhead denotes the strong expression in the developing inner ear.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
