FIGURE

Figure 4

ID

ZDB-FIG-200811-44

Publication

Imperatore et al., 2020 - Immunohistochemical Analysis of Intestinal and Central Nervous System Morphology in an Obese Animal Model (Danio rerio) Treated with 3,5-T2: A Possible Farm Management Practice?

Other Figures

All Figure Page

Back to All Figure Page

Figure 4

COX2 immunostaining in the anterior (AI) and mid (MI) intestine of ctrl (control zebrafish), D.I.O. (diet-induced obesity zebrafish), D.I.O. flw 3,5–T2 (D.I.O. zebrafish followed by 3,5–T2), D.I.O. with 3,5–T2 (D.I.O. zebrafish treated with 3,5–T2). (A) AI of ctrl zebrafish (B) AI of D.I.O. (C) AI of D.I.O. flw 3,5–T2. (D) AI of D.I.O. with 3,5–T2. (E) MI of ctrl zebrafish. (F) MI of D.I.O. (G) MI of D.I.O. flw 3,5–T2. and (H) MI of D.I.O. with 3,5–T2. The arrows indicate COX2 immunoexpression in the enteroendocrine and goblet cells. (I,J) Bar graphs showing COX2 optical density (O.D.) in the (I) AI and (J) MI of ctrl, D.I.O., D.I.O. flw 3,5–T2 and D.I.O. with 3,5–T2. Data are expressed as mean ± SE. ** p < 0.001, * p < 0.05 compared to the control group. ° p < 0.05 compared to D.I.O. Scale bar: 100 μm in the low magnification and 50 μm in the higher magnification in the boxes.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Animals (Basel)
