Fig. 3

sept8a expression in the CNS of 2 dpf zebrafish.

Images of transverse epon sections of 2 dpf zebrafish stained for sept8amRNA and counterstained with Hoechst33258 (B – H). Section levels and angle are displayed in the schematic drawing (A). sept8a expression was weakly detectable in cells in the entire brain (B – H), as well as in the retina (C – E) and the lens (C, D). Strong sept8a expression was observed in two large nuclei (arrowheads) close to the SR (G). See list for abbreviations. Brain schemes were modified from Müller and Wullimann (2016). Scale bars: B – H: 100μm Insets: 25μm.

Expression Data

Gene:	septin8a
Fish:	mitfa^w2/w2; mpv17^b18/b18
Anatomical Terms:	caudal tuberculum dorsal telencephalon eye hypothalamus Mauthner neuron medulla oblongata optic tectum pharyngeal arch 3-7 preoptic area tegmentum thalamus ventral telencephalon (all 12)
Stage:	Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 25-26, Berger, C., Helmprobst, F., Chapouton, P., Lillesaar, C., Stigloher, C., sept8a and sept8b mRNA expression in the developing and adult zebrafish, 8-21, Copyright (2017) with permission from Elsevier. Full text @ Gene Expr. Patterns
