Fig. 3

Ectopic expression of tcf21 and tbx18 in the cardiac and pharyngeal arch regions by wtip mRNA overexpression. Ventral view of 48 hpf whole-mount in situ hybridization of (A,B) tcf21 and (C,D) tbx18) in (A,C) control and (B.D) wtip mRNA-injected embryos (92 pg/embryo). The ectopic expression of tcf21 (black arrows in B) and tbx18 (black arrows in D) expression in the heart region compared with control tcf21 (yellow arrowhead in A) and tbx18 (yellow arrowhead in C) expression in the PE region of the heart. tbx18 expression in the pectoral fin (black asterisk in C) was unaffected in wtip mRNA-injected embryos. tcf21, transcription factor 21; tbx18, Tbox 18; wtip, Wilm′s tumor 1 interating protein; hpf, hours post fertilization; PE, proepicardial organ.

Expression Data

Genes:	tbx18 tcf21
Fish:	AB
Anatomical Terms:	pectoral fin pharyngeal arch proepicardial cluster
Stage:	Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
