Fig. S5

Knockdown of irf4a turns irf4a-expressing lymphoid cells to lyz-expressing myeloid cells without affecting erythroid lineage.

(A) The expression of erythroid cells markers, gata1 and βe1-globin in the control and irf4a morphants at 4 dpf. The red arrows indicate cells expressing gata1 or βe1-globin. (B) The expression of coro1a in the control and irf4a morphants at 3 dpf examined by WISH. Black arrowhead indicates the thymus and red arrow indicates coro1a-expressing cells in the CHT. (C) qPCR analysis of coro1a expression in the control and irf4a morphants at 3 dpf. ns, not significant. (D) Confocal images of irf4a-expressing cells in the CHT region of the irf4a:GFP transgenic embryos at 60 hpf (scale bar, 80 µm). The magnified view of irf4a-expressing cell is shown in the right panels (scale bar, 10 µm). (E) Still images of a time-lapse imaging of double transgenic (irf4a:GFP/ lyz:DsRed) wild-type and irf4a morpholino injected embryos. The time-lapse series begins at 58 hpf. White or red arrows indicate the same cell in the control or irf4a morphants respectively (scale bar, 40 µm). All data are means ± SD.
