Fig. 1

Skolios mutants develop recessively inherited curvature of the body axis. A: Ventral curvature phenotypes observed in skolios mutant embryos at 3 dpf. B: Relative frequencies of ventral curvature phenotypes in WT and skolios embryos (3 dpf). C: Dorsal view of embryonic (4 dpf) and juvenile (17 dpf) zebrafish showing development of sagittal body curvature in skolios mutants. D: Severe body curvature in both the medial–lateral and dorsal–ventral planes of an adult skolios mutant. E: MicroCT imaging at approximately 50 dpf shows marked curvature of the abdominal (rib vertebrae) and caudal (vertebrae posterior to ribs) spine in skolios mutants.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	kif6^gw326/gw326
Observed In:	caudal vertebra precaudal vertebra vertebral column whole organism anterior-posterior axis whole organism dorsal-ventral axis whole organism medial-lateral axis (all 6)
Stage Range:	Protruding-mouth to Adult
