Fig. 1

ptpn9a is expressed in the primitive hematopoietic sites during zebrafish embryogenesis. RNA in situ hybridization with ptpn9a probe in one-cell (A), 6-hpf (B), 15-hpf (C), 18-hpf (D), 24-hpf (E) and 36-hpf (F) embryos. Note ptpn9a expression in the posterior lateral plate mesoderm (PLPM) (C; red arrowhead) and the intermediate cell mass (ICM) (D,E; red arrowheads) regions. Lateral views are shown with anterior to the left (D–F), and dorsal views are shown with anterior to the top (C).

Expression Data

Gene:	ptpn9a
Fish:	WT
Anatomical Terms:	blastomere brain intermediate cell mass of mesoderm posterior lateral plate mesoderm whole organism
Stage Range:	1-cell to Prim-25
