Malicki et al., 1996 - Mutations affecting development of the zebrafish retina. Development (Cambridge, England) 123:263-273 Full text @ Development

ADDITIONAL FIGURES

PHENOTYPE:

Fish:	dctn1a^m632/m632 (AB) krt^m699/m699 (AB) nie^m743/m743 (AB) sid^m604/m604 (AB) traf3ip1^m649/m649 (AB)
Observed In:	brain eye retinal photoreceptor layer
Stage:	Day 5

Fig. 4

Head and trunk phenotypes of mutations predominantly affecting development of the outer retina. (A) Wild type. (B) mikre oko (mok)^m632. (C) niezerka (nie)^m743. (D) elipsa (eli)^m649. (E) krenty (krt)^m699. (F) sinusoida (sid)^m604. Mutants in B, C, E and F have smaller eyes than the wild type. Eyes of eli^m649 have abnormal oval shape (D). The brain shape defect is most pronounced in krt^m699. In all panels anterior is to the left and dorsal is up. All phenotypes were photographed at 5 dpf.

Gene Expression Details No data available

Antibody Labeling Details No data available

Phenotype Details

Fish	Conditions	Stage	Phenotype
dctn1a^m632/m632 (AB)	standard conditions	Day 5	eye decreased diameter, abnormal
		Day 5	retinal photoreceptor layer absent, abnormal
krt^m699/m699 (AB)	standard conditions	Day 5	brain shape, abnormal
		Day 5	eye decreased diameter, abnormal
nie^m743/m743 (AB)	standard conditions	Day 5	eye decreased diameter, abnormal
		Day 5	retinal photoreceptor layer absent, abnormal
sid^m604/m604 (AB)	standard conditions	Day 5	brain shape, abnormal
		Day 5	eye decreased diameter, abnormal
		Day 5	retinal photoreceptor layer structure, abnormal
traf3ip1^m649/m649 (AB)	standard conditions	Day 5	eye elliptic, abnormal
