ZFIN Figure: Zuniga et al., 2011, Fig. 5

ZFIN ID: ZDB-FIG-111128-63

ZFIN ID: ZDB-FIG-111128-63

Zuniga et al., 2011 - Gremlin 2 regulates distinct roles of BMP and Endothelin 1 signaling in dorsoventral patterning of the facial skeleton. Development (Cambridge, England) 138(23):5147-5156 Full text @ Development

ADDITIONAL FIGURES

EXPRESSION / LABELING:

Genes:	dlx3b hand2 msx1a
Fish:	edn1^{tf216b/tf216b} kca4Tg el49Tg; kca4Tg edn1^{tf216b/tf216b}; el49Tg; kca4Tg
Condition:	heat shock
Anatomical Terms:	mandibular arch skeleton pharyngeal arch cranial neural crest cell pharyngeal arch 1 pharyngeal arch 1 central region
Stage:	Prim-25

Fig. 5 Bmp4 induces hand2 and msxe expression in the absence of Edn1. (A-P) Confocal sections of 36 hpf in situ hybridizations for hand2 (green) with dlx3b (red, A-H) or msxe (red, I-P) in control hsp70I:Gal4 (A,I), edn1^-/- mutant (E,M), UAS:Bmp4 (B-D,J-L) and edn1^-/-; UAS:Bmp4 (F-H,N-P) embryos. Increasing periods of Bmp4 heat-shock induction [1 minute at 21 hpf (B,F,J,N), 3 minutes at 21 hpf (C,G,K,O) and 4 hours from 20-24 hpf (D,H,L,P)] resulted in progressive recovery of hand2 and msxe but not dlx3b expression in edn1^-/- mutants. Consistent phenotypes were observed for the following: (A) n=55, (B) n=31, (C) n=15, (D) n=9, (E) n=8, (F) n=3, (G) n=4, (H) n=1, (I) n=37, (J) n=11, (K) n=6, (L) n=9, (M) n=20, (N) n=2, (O) n=3 and (P) n=2. Scale bar: 50 μm.

Gene Expression Details

Gene	Fish	Conditions	Stage	Qualifier	Anatomy	Assay
dlx3b	edn1^{tf216b/tf216b}	heat shock	Prim-25	Not Detected	pharyngeal arch 1 central region	ISH
	edn1^{tf216b/tf216b}; el49Tg; kca4Tg	heat shock	Prim-25	Not Detected	pharyngeal arch 1 central region	ISH
	el49Tg; kca4Tg	heat shock	Prim-25		mandibular arch skeleton	ISH
	kca4Tg	heat shock	Prim-25		pharyngeal arch 1 central region	ISH
hand2	edn1^{tf216b/tf216b}	heat shock	Prim-25	Not Detected	pharyngeal arch cranial neural crest cell	ISH
	edn1^{tf216b/tf216b}; el49Tg; kca4Tg	heat shock	Prim-25	Not Detected	pharyngeal arch cranial neural crest cell	ISH
	el49Tg; kca4Tg	heat shock	Prim-25		pharyngeal arch cranial neural crest cell	ISH
	kca4Tg	heat shock	Prim-25		pharyngeal arch cranial neural crest cell	ISH
msx1a	edn1^{tf216b/tf216b}	heat shock	Prim-25	Not Detected	pharyngeal arch 1	ISH
	edn1^{tf216b/tf216b}; el49Tg; kca4Tg	heat shock	Prim-25	Not Detected	pharyngeal arch 1	ISH
	el49Tg; kca4Tg	heat shock	Prim-25		pharyngeal arch 1	ISH
	kca4Tg	heat shock	Prim-25		pharyngeal arch 1	ISH

Antibody Labeling Details No data available

Phenotype Details No data available
