FIGURE

Fig. 3

ID

ZDB-FIG-110322-31

Publication

Pikulkaew et al., 2011 - The knockdown of maternal glucocorticoid receptor mRNA alters embryo development in zebrafish

Other Figures

All Figure Page

Back to All Figure Page

Fig. 3

Phenotypes of embryos or larvae at 1, 3, and 5 dpf after treatment with gr^ATG1MO alone or together with MOp53 as compared to control groups (WT or treated with gr^mismMO or gr^splicMO) or after rescuing with t-gr2 mRNA. Fish in Class II are more severely affected than in Class I. Animals are presented as lateral view, anterior to the left. Bar = 500 µm. The effects of gr^ATG2MO are also shown.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO2-nr3c1 WT + MO3-nr3c1
Knockdown Reagents:	MO2-nr3c1 MO3-nr3c1
Observed In:	brain embryo development extension eye head otic vesicle pericardium pigmentation
Stage Range:	Prim-5 to Day 5

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
