Fig. 4
- ID
- ZDB-FIG-101118-4
- Publication
- Chitramuthu et al., 2010 - Progranulin modulates zebrafish motoneuron development in vivo and rescues truncation defects associated with knockdown of Survival motor neuron 1
- Other Figures
- (all 8)
- All Figure Page
- Back to All Figure Page
zfPGRN-A knockdown results in disrupted development of multiple neural structures. Lateral views of whole-mount embryos probed with islet 1 at 36 hpf. (A), uninjected embryos (B) embryos injected with zfPGRN-A MO2 (C) embryos injected with 100 pg zfPGRN-A mRNA, or (D) embryos co-injected with zfPGRN-A MO2 + 100 pg zfPGRN-A. 96% (48/50) of uninjected embryos (A) and 90% (45/50) of embryos injected with 100 pg zfPGRN-A mRNA (B) showed islet1 expression in the developing hypothalamus, retinal ganglia, sensary ganglia and pharyngeal arches. 84%(31/37) of embryos injected with 10 ng of zfPGRN-A MO2 (C) showed disrupted development of multiple neural structures. Co-injection of embryos with 10 ng MO2 and 100 pg zfPGRN-A mRNA (D) resulted in the rescue of 80% (40/50) embryos displaying islet 1 positive neural populations. Scale Bar = 100 μm |
Gene: | |
---|---|
Fish: | |
Knockdown Reagent: | |
Anatomical Terms: | |
Stage: | Prim-25 |
Fish: | |
---|---|
Knockdown Reagent: | |
Observed In: | |
Stage: | Prim-25 |
