Fig. 2

Expression of ptc1 in two Hh pathway mutants and in embryos in which shh RNA has been overexpressed. Dorsal views of 24 hpf whole-mount otic vesicle preparations showing ptc1 expression. Anterior towards the left, lateral towards the bottom. Scale bar: 50 μm. Note that ptc1 expression is much weaker in con^tf18b homozygotes (B) than in wild-type embryos (A; a sibling of the con^tf18b homozygote). ptc1 expression is undetectable in the smu^b641 otic vesicle (C) and is upregulated throughout the vesicle in embryos in which shh has been overexpressed by injection of 100ng/μl shh RNA (D).
