Fig. S7

Syk and Zap morphants lack a thoracic duct. Angiography in wild type Tg(fli1a:EGFP)^y1 embryos shows a clear separation between the dorsal aorta and posterior cardinal vein, and the presence of the thoracic duct lacking dye between the two vessels (A, A′). Conversely, angiography in syk^LO (B, B′), zap-70^LO (C, C′), and syk^LO:zap-70^LO double morphants (D, D′) demonstrates the clear lack of a thoracic duct between the artery and vein. In syk^LO:zap-70^LO double morphants, some ISVs also appear to have restricted or lack blood flow.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	y1Tg + MO1-syk y1Tg + MO2-zap70 y1Tg + MO1-syk + MO2-zap70
Knockdown Reagents:	MO1-syk MO2-zap70
Observed In:	thoracic duct
Stage:	Day 5

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 340(1), Christie, T.L., Carter, A., Rollins, E.L., and Childs, S.J., Syk and Zap-70 function redundantly to promote angioblast migration, 22-29, Copyright (2010) with permission from Elsevier. Full text @ Dev. Biol.
