FIGURE

Fig. S5

ID

ZDB-FIG-090915-45

Publication

Chen et al., 2009 - Repression of RNA polymerase II elongation in vivo is critically dependent on the C-terminus of Spt5

Other Figures

All Figure Page

Back to All Figure Page

Fig. S5

P-TEFb is required for NSpt5’s in vivo effects. (A-D) The morphological phenotypes of CDK9 morpholino-injected (B), NSpt5-expressing (C), or CDK9 morpholino-injected and NSpt5-expressing (D) embryos. (E-F) flavopiridol (FP) treated (E) embryos as compared to FP treated and NSpt5-expressing embryos (F). (G-I) The morphological phenotypes of CDK9 morpholino-injected (G), NSpt5-expressing (H), or CDK9 morpholino-injected and NSpt5-expressing (I) embryos at later developmental stages. These studies show that impairment of CDK9 activity partially suppressed the dorsalization phenotype of NSpt5-expressing embryos. (J-K) Quantitative RT-PCR analyses show that both CDK9 MO and FP treatment decreases hsp70 transcripts induced by NSpt5. Abbreviations, h, head; t, tail; y, yolk.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ PLoS One
